Trade Assurance Fullwon Supplier SINOTRUK HOWO 371HP 6X4 Tractor Head Truck

FOB Reference Price:Get Latest Price
$30,000.00 - $40,000.00 / Unit | 1 Unit/Units (Min. Order)
Customization:
Graphic customization (Min. Order: 5 Units)
Report Suspicious Activity
Overview
Quick Details
Brand Name:
Fullwon
Size:
7350*2496*3005mm
Transmission Type:
Automatic
Condition:
New
Horsepower:
371hp
Emission Standard:
Euro 2
Drive Wheel:
6x4
Fuel Type:
Diesel
Gross Vehicle Weight:
9230 kg
Engine Rated Power (HP/r/min):
420HP/309kw, 2000r/min
Engine Max. Torque (Nm/r/min):
1800Nm ,1100~1400r/min
Supply Ability
Supply Ability:
1000 Unit/Units per Month
Packaging & Delivery
Packaging Details
standard packaging
Port
Shanghai port or any other port in China

1620



Product Description
DimensionsLength (mm)7350
Width (mm)2496
Height (mm)3005
Wheel Base (mm)3825+1350
Wheel track (Frong/rear mm)2022/1830
Front /rear suspension(mm)1500/725
Approach/Departure Angle (°)16/70
WeightVehicle Curb Weight (kg)9230
Tractor Weight(kg)40000
Gross Comb. Weight (kg)25000
Gross Comb. Weight (design)25000
PerformanceMax. Speed (km/h)102
Max. Speed (km/h)(design)102
Fuel Consumption (L/100km)40

Core Equipments Specifications

EngineModelD12.42-20 Diesel engine,EURO II stage,6-cylinder in line,4-stroke,water-cooled,turbocharged,air-to-air intercooled
Rated Power (HP/r/min)420HP/309kw, 2000r/min
Max. Torque (Nm/r/min)1800Nm ,1100~1400r/min
TypeSINOTRUK made
ClutchModelStandard A-type (Standard WABCO clutch master cylinder,wheel cylinder)
TypeSINOTRUK 430 pull-type diaphragm clutch
TransmissionTypeHW19710, Max.torque1900Nm
Speed10 gears
FrameType & AdvantagesMAN Frame,Enhanced whole front suspension brackets and beams to Improve the reliability of the engine and cab suspension
Large span beams connecting plate and local reinforcement structure  make  stress distribution more uniform
Stringer standard pitch design in favour of Modular layout  and option of the assembly of different wheelbase
Front AxleTypeSINOTRUK MADE, HF9, Howo new Style,Standard drum brakes
Ratio Load(kg)9000
FR. SuspensionTypeNew SINOTRUK style, spring suspension
Rear AxleTypeSteyr 16T Double reduction axle
Ratio Load(kg)16ton *2
ReductionRatio: 3.93/4.42
RR. SuspensionTypeNew SINOTRUK style, spring suspension
SteeringModel8098
Typesteering ,power steerig pump,system pressure18Mpa
Steering Wheelhydraulic steering
Brake SystemParkingDrum brake

Standard Equipments Specifications

Driver’s Cab.TypeHW76,VOLVO cab,with one sleeper, Right Hand Drive
 New style seat, Single Sleeper, Adjustable steering wheel,European new heaters,Large LCD display,VDO Instrument and electrical control template,Four-point suspension and shock absorber,Lateral stability device,Dual-locking structure of seat belt,exterior sun shade
Driver's SeatHydraulic shock absorbers
Air conditionerAir condition
Fuel TankCapacity (L)500L+500L
Wheel&TireType & Size315R22.5 Tubeless Tire
Fifth WheelTypeSinotruk made, #50
ElectricalBatteries24V

Annotations

1) This vehicle specifications may differ per country and allow for production tolerance
2) Manufacture reserves the right to modify the design and equipments without prior notice
3)Means standard equipment
4)The prices are valid for the following 30 days
5)Product color because of color difference,take material object as standard



--1_09(1)

--1_11







Q: How can we trust your company?

A: We are the officially authorized 4S dealer and distributor of some famous brands such as SINOTRUK, LONKING and

VOLVO. And we are registered in the Commercial Department of China, with the whole qualification for exporting.

Certificates including ISO9001 can also be provided.





Q: How about your warranty item?

A: We can support you with original spare parts, and email or telephone assistance in the following days. If necessary, our

experienced engineer can go abroad to your place for technical support.





Q: How about your product quality?

A: All our products are from the original manufacturers and the quality is 100% guaranteed.

Q:Can I be your agent in my country ?





Q:Can I be your agent in my country ?

A: It's OK if the order quantity is appropriate. We looks forward to long-term cooperation.
